167258 NAPPK DALI-0-10V-PWM-2CH-CAS

< Back

L70 x W68 x H27 mm

WT: 0.055 kg

Product description

12...57 Vdc input
This wireless control unit boasts two PWM dimmers for your 12...57 Vdc LED strips
As well as two 0-10V dimming outputs and one DALI dimming output
Commissioned via smart mobile app; compatible devices: IOS and Android operating systems
Utilizes bluetooth mesh technology for reliable and secure wireless communication
The device provides you with a variety of control options, a variety of control modes freely switch to choose

Swipe for more

Rated input voltage range:	12...57 Vac
Max. input current:	6 A
RF transmit power:	+ 8 dBm
Wireless frequency:	2.4 GHz
Wireless range (open air):	50 m
Output voltage 0-10V:	0...10 Vdc
Output voltage DALI:	12 Vdc
Output current DALI:	20 mA
Output current 0-10 V:	10 mA

Product name	Input voltage	DALI	0-10V
NAPPK DALI-0-10V-PWM-2CH-CAS	12-57 Vac	20 mA	0-10V 10 mA

Operating temperature:	-20…+55℃
Storage temperature:	-25…+75℃
Working humidity:	10%…90%
Store humidity:	5%…95%
Driver lifetime:	50,000 hrs
Moisture and dust rating	IP20
