164530 ID ELSCB 31/230/350-900 DALI DIP

< Back

L360 x W20 x H11 mm

WT: 0.1352 kg

Questions Order a Sample

Product description

Standby power consumption＜0.3 W, meets ErP energy efficiency certification
Smooth dimming with dimming range 1-100% (amplitude dimming)
Equipped with i-Data enabling data managament according to DALI parts 251, 252 and 253 (luminaire data, energy reporting, diagnostic & maintenance)
Supports DALI-2, push DIM, corridor mode, CLO
DlP switch for multi-current setting

General Data
Electrical Operating Data
Environmental Data
Packaging Information
Downloads

Rated input voltape range:	220...240 Vac
Max.input voltage range:	198...264 Vac
Rated input current DC range:	220...240 Vdc
DC operation voltage range:	176...280 Vdc
Safety frequency range:	50/60 Hz
Rated input current:	0.17 A @ 230 Vac
THD:	20%
Inrush current [Aµs]:	72.5 Aµs
MCB Quantity B10A:	53
MCB Quantity C10A:	53
MCB Quantity B16A:	86
MCB Quantity C16A:	86
Output current tolerance:	± 5%
Output voltage max.:	50 Vdc
Ripple:	≤ 5%
Standby power consumption:	< 0.4 W@230 Vac
Output PstLM:	≤ 1
Output SVM:	≤ 0.4
Dimming mode:	DALI-2, push DIM
Dimming range:	1%...100%
Adjustable output current:	DIP
Withstand voltage:	I/P-O/P: 3 kVac, < 5mA 60 sec; I/P-DA/P: 1.5 kVac, < 5 mA 60 sec; O/P-DA/P: 1.5 kVac, < 5 mA 60 sec

Operating temperature:	-20...+55℃
Storage temperature:	-25...+85℃
Working humidity:	10%...90%
Store humidity:	5%...95%
Driver lifetime:	50000 hrs
Maximum Tc temperature:	80℃

Pcs./ carton:	70 pcs
Carton size:	381 x 215 x 116 mm
Gross weight:	10.2kg

Data sheets
Approvals
3D Drawing
Declaration

CE-EMC_ID_ELSCB_31_230_350-900_DALI_DIP
CE-LVD_ID_ELSCB_31_230_350-900_DALI_DIP
ENE_ID_ELSCB_31_230_350-900_DALI_DIP
Download all

New products

ID ECSCB 200/230/150-1050 NFC OUT

NAPPK PWM5CH-CAS

NALNR54-1400D-NFC-CAS

NALNR54-1400D-010V-NFC

*mandatory information

I would like to receive the CUPOWER Light News and personal information. I consent to the use of my provided personal data for the purpose of sending the newsletter. I acknowledge the information on data processing and the right to withdraw my consent, as outlined in the CUPOWER data protection information.

> More about CUPOWER data protection

Product name	Output current	Input voltage	Output voltage	Efficiency @full load	Current accuracy	Power factor
ID ELSCB 31/230/350-900 DALI DIP	350...900 mA	220...240 Vac	12...38 V	90%	± 5%	> 0.9
